Characterized by its light body, small turning radius, and ease of operation, the Manual Hydraulic Forklift is well-suited for applications in the mold processing industry, logistics and warehouses, yards, supermarkets, and other similar environments. The body incorporates advanced spray technology to ensure a thicker and more solid paint coat, enhancing durability and maintaining the product's aesthetic appeal. Not only economically priced, but also highly practical, these equipment options provide a cost-effective solution for various material handling requirements.
1.It applies C type steel structure design , Lifting more stable and safe.
2.AIll Manual stacker have been equipped with wheel frame protection device.
3.The handle have been surround with rubber.With lengthening design,Using more comfortable.
4.Single Frame have two ways to unload by manual and pedal,using more flexible.
5.Fork with adjustable nut ,it can easy to adjust the fork height.
6.Wheel frame equipped with grease ftting design,It will help do routine maintenance for bearing.
7.There are too many kinds of Fork types,Fixed Fork, Adjusting fork,also with the adjusting wide leg or Fixed wide leg.
Specifications 参数 | |||||||||||
Standard 标准 | 1.1 | Manufacturer | 制造厂商 | NOELIFT | NOELIFT | NOELIFT | NOELIFT | NOELIFT | NOELIFT | NOELIFT | |
1.2 | Model | 型号 | SYC0516 | SYC1016 | SYC1516 | SYC2016 | SYC1020/1520/2020 | SYC1025/1525 | SYC1030/1530 | ||
1.3 | Power type | 动力类型 | Manual 手动 | Manual 手动 | Manual 手动 | Manual 手动 | Manual 手动 | Manual 手动 | Manual 手动 | ||
1.4 | Rated load | 额定载荷 | kg | 500 | 1000 | 1500 | 2000 | 1000/1500/2000 | 1000/1500 | 1000/1500 | |
1.5 | Load center | 载荷中心距 | mm | 500 | 500 | 500 | 500 | 500 | 500 | 500 | |
Weights 重量 | 2.1 | Service Weight | 整车重量 | kg | 150 | 224 | 240 | 270 | 290 | 310 | 330 |
Wheels 车轮 | 3.1 | Load wheel size | 载重轮尺寸 | mm | Φ180*50 | Φ180*50 | Φ180*50 | Φ180*50 | Φ180*50 | Φ180*50 | Φ180*50 |
3.2 | Front wheel size | 前轮尺寸 | mm | Φ80*58 | Φ80*58 | Φ80*58 | Φ80*58 | Φ80*58 | Φ80*58 | Φ80*58 | |
3.3 | Number of wheels,front/rear | 车轮数量,前/后 | 2/2 | 2/2 | 2/2 | 2/2 | 2/2 | 2/2 | 2/2 | ||
Size 尺寸 | 4.1 | Max. Lift height | 最大起升高度 | mm | 1600 | 1600 | 1600 | 1600 | 2000 | 2500 | 3000 |
4.2 | Minimum height of fork surface | 货叉面最小离地高度 | mm | 85 | 85 | 85 | 85 | 85 | 85 | 85 | |
4.3 | Overall dimension | 整车尺寸 | mm | 1600*760*2030 | 1600*760*2030 | 1600*760*2030 | 1600*760*2030 | 1600*760*1580 | 1600*760*1840 | 1600*760*2080 | |
4.4 | Fork Length | 货叉长度 | mm | 1000 | 1150 | 1150 | 1150 | 1150 | 1150 | 1150 | |
4.5 | Fork width | 货叉宽度 | mm | 330-740 | 330-740/550 | 330-740/550 | 330-740/550 | 330-740 | 330-740 | 330-740 | |
4.6 | Leg width | 支腿宽度 | mm | 690 | 690 | 690 | 690 | 690 | 690 | 690 | |
Others 其他 | 5.1 | Mast type | 门架类型 | Single type 单门架 | Single type 单门架 | Single type 单门架 | Single type 单门架 | Duplex mast 双门架 | Duplex mast 双门架 | Duplex mast 双门架 |
1. One-stop solutions offer
2. OEM services offer
3. 24 hours non stop service offer
4. Track the products for you once every two days, until you get the products.
5. During warranty, spare parts delivery within one week for free.
Q1: Are you an electric forklift factory?
A1: Yes, we have been a professional manufacturer of electric forklifts for more than 15 years.
Q2: How about the delivery time?
A2: About 20-30 days based on different models. For some standard products, we may have stock and could deliver immediately.
Q3: Is a customized solution available?
A3: Yes, we can provide different customized solutions.
Q4: Can you provide OEM service?
A4: Yes.
In order to provide our customers with logistics handling solutions ranging from 500kg to 100,000kg, Noelift can provide you with an electric pallet truck, pallet stacker, counterbalance stacker, reach truck, stand-on reach truck, seated reach truck, reach stacker, electric counterbalance forklift truck, counterbalance forklift, tow tractor, order picker, narrow aisle forklift, 4-direction reach truck, 3-way pallet stacker(VNA), multi-direction forklift, AGV, and other customized types of options. All Noelift products are extensively utilized in the food, pharmaceutical, chemical, home electrical appliance, wool cotton textile, tobacco, electronics, machinery, furniture, and many other industries because of product serialization and standardization.
