Environmental Protection and Energy Saving: Compared to traditional internal combustion forklifts, electric forklifts emit virtually no exhaust during operation, significantly reducing environmental pollution. Furthermore, their electric drive makes them more energy-efficient and reduces operating costs.
Low Noise: Electric forklifts' electric motors operate much quieter than internal combustion engines, creating a quieter working environment in warehouses and workshops, promoting employee well-being.
Easy Operation: forklift noelift electric generally utilize electronic control systems with intuitive and user-friendly interfaces, simplifying operation and improving efficiency.
Low Maintenance Cost: battery forklift trucks have a relatively simple structure, resulting in less wear on components, thus reducing maintenance costs. Furthermore, with the continuous advancement of battery technology, battery life is also increasing.
Suitable for loading, unloading, and stacking medium-to-heavy cargo.
Suitable for container loading and unloading and for applications with limited height.
Can be equipped with a variety of attachments to meet the needs of different working conditions.
| Standard标准 | |||
| 1.1 | Manufacturer | NEOLIFT | |
| 1.2 | Model | TK15 | |
| 1.3 | Power Type | Battery | |
| 1.4 | Operation Type | Driving Style | |
| 1.5 | Rated Capacity | Q(kg) | 1500 |
| 1.6 | Load Center | C(mm) | 500 |
| 1.8 | Front Overhand | x(mm) | 380 |
| 1.9 | Wheelbase | y(mm) | 1380 |
| Weight重量 | |||
| 2.1 | Service Weight(incl.battery) | kg | 2900 |
| Wheel轮胎 | |||
| 3.1 | Wheel Types | Pneumatic tire | |
| 3.2 | Load Wheel | mm | 5.00-8 |
| 3.3 | Drive wheel | mm | 6.00-9 |
| 3.5 | Number of wheels,,front/rear(x=drive wheel) | 2x/2 | |
| 3.6 | Wheel tread,drive side | b10(mm) | 910 |
| 3.7 | Wheel tread,load side | b11(mm) | 930 |
| Size尺寸 | |||
| 4.1 | Mast tilting | α/β(°) | 6/10 |
| 4.2 | Mast closed height | h1(mm) | 1995 |
| 4.3 | Free lift height | h2(mm) | 135 |
| 4.4 | Lift height | h3(mm) | 3000 |
| 4.5 | Mast extended height with load-backrest | h4(mm) | 4030 |
| 4.7 | Overhead guard height | h6(mm) | 2100 |
| 4.8 | Seat height | h7(mm) | 1090 |
| 4.19 | Overall length | L1(mm) | 3205 |
| 4.20 | Length to fork face | L2(mm) | 2135 |
| 4.21 | Overall width | b1(mm) | 1110 |
| 4.22 | Fork size | l/e/s(mm) | 1070/100/35 |
| 4.23 | Installation level | 2A | |
| 4.24 | Fork carriage width | b3(mm) | 1040 |
| 4.25 | Fork outside width | b5(mm) | 222～1000 |
| 4.31 | Mast ground clearance | m1(mm) | 85 |
| 4.32 | Body ground clearance | m2(mm) | 100 |
| 4.34.1 | Aisle width for pallet 1000*1200 | Ast(mm) | 3580 |
| 4.34.2 | Aisle width for pallet 800*1200 | Ast(mm) | |
| 4.35 | Turning radius | Wa(mm) | 2000 |
